CCM Continuous Casting Equipment Horizontal Continuous Casting Machine Full Arc Type

1
MOQ
Negotiation
Price
CCM Continuous Casting Equipment Horizontal Continuous Casting Machine Full Arc Type
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Machining Parts
Spare Parts Type: Machining Parts
Key Selling Points: Competitive Price
Highlight:

Horizontal Continuous Casting Machine

,

Full arc type CCM Machine

,

CCM Continuous Casting Equipment

Basic Infomation
Place of Origin: Shaanxi, China
Brand Name: AE
Certification: CE;ISO9001;ISO14001;OHSAS 18001
Payment & Shipping Terms
Delivery Time: 30-90work days
Product Description

                        CCM Continuous Casting Machine

CCM Continuous Casting Machine Continuous Casting and Rolling Equipment for Machining Parts CCM at Manufacturing Plant CCM

Product Description

Type of caster   Full arc type Continuous casting machine

Radius of the arc (m)     R4-8m

Distance between strands (mm)      1250

Number of strand   1-10Strands

Cross section of billet (mm)      80*80-200*200mm

Length of billet (m) 3-12m

Casting steel grade :   Normal carbon steel, low allow steel, bearing steel

Casting speed m/min    0-3.5

Dummy bar sending speed m/min  0.5 - 4

Dummy bar type     Rigid dummy bar

Casting way      Sliding nozzle - Immersion long nozzle - Protection slag

Billet cutting method     Flame cutting machine

Billet out going mode    Terminal roller table - chain type removing machine -sliding rails cooling bed

total length of the caster (m)     about 40

Description:
Dummy bar is used in continuous casting machine. It is used to guide the billet.

Application:
The dummy bar is used to tract and lead the cooled and solidified strand and put it out by the withdrawal and straightening machine.

Features:
In order to avoid the deformation of dummy bar body due to heating, the dummy bar is  equipped with a cooling water pipe inside the bar body. It has the features of smaller deformation, long service life, simple structure and installation, easy operation and maintenance.

Specification:
1. CCM machine parts
2. Diversified arc radius
3. Diversified strands
4. More operations for CCM machine

CCM Continuous Casting Equipment Horizontal Continuous Casting Machine Full Arc Type 0


Technical Parameter:


Outer bow radius of bar body

R3000mm,R4000mm, R5250mm,R6000mm, R7000mm, R8000mm,R10000mm

Section dimension of bar body

80x80mm,100x100mm,120x120mm,150x150mm,160x160mm,180x180mm,200x200mm
