Electric Arc Furnace Steel Melting Furnace with 3T-150T Capacity 800kW Power and PLC Control System

1
MOQ
Negotiation
Price
Electric Arc Furnace Steel Melting Furnace with 3T-150T Capacity 800kW Power and PLC Control System
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Arc Furnace
Warranty Of Core Components: 1 Year
Core Components: PLC
Key Selling Points: Competitive Price
Highlight:

800kW Electric Arc Furnaces

,

150T Electric Arc Furnaces

,

3T Electric Arc Furnaces
Basic Infomation
Place of Origin: Shaanxi, China
Brand Name: AE
Certification: CE;ISO9001;ISO14001;OHSAS 18001
Payment & Shipping Terms
Delivery Time: 30-90work days
Product Description
Electric Arc Furnaces for Steel Production Line (3T-150T, 800kW Power)
Product Overview
The electric arc furnace uses electricity as its fuel source, utilizing the high-temperature arc produced between electrodes and furnace charge to heat and melt materials. This equipment is essential for producing various steel grades including normal steel, high-quality carbon steel, alloy steel, stainless steel, and ferroalloys. It serves as a key component in steel mills, foundries, and ferrous alloy production facilities.
Key Features
  • Flexible temperature control for diverse steel grade production
  • High heat efficiency with controllable furnace atmosphere
  • Effective removal of phosphorus, sulfur, oxygen and other impurities
  • Precise chemical composition control with stable alloy recovery rates
  • Simplified equipment design with shorter processing workflow
Advanced Technologies
  • Optimized structural design
  • Tubular water-cooled furnace wall and lid
  • Eccentric bottom tapping (EBT) system
  • Copper-steel combined electrode arm
  • Cluster-type large sectional area water-cooled cables
  • Energy-saving large current system structure
  • Proportional valve hydraulic system
  • PLC + industrial computer control system
  • Frequency control and network technologies
Complete System Components
Includes furnace body, tilting mechanism, furnace cover, bracket, lifting/rotating mechanisms, electrode systems, cooling system, compression system, hydraulic system, transformer, oxygen lance devices, power supply systems, and computer/PLC control system.
Technical Specifications
Type Rated Capacity (T) Max Capacity (T) Furnace Shell Inner Diameter (MM) Electrode Diameter (MM) Transformer Capacity (KVA)
EAF-5T 5 10 3200 300 2500-4300
EAF-10T 10 18 3600 350 5500-8000
EAF-15T 15 24 3800 350 8000-12500
EAF-20T 20 30 4000 400 9000-12500
EAF-25T 25 35 4200 400 12500
EAF-30T 30 45 4400 400 12500-25000
EAF-40T 40 55 4600 450 16000-30000
EAF-45T 45 65 4800 450 16000-40000
EAF-60T 60 85 5400 500 25000-60000
EAF-80T 80 100 6100 500 30000-80000
EAF-100 100 120 6400 550 40000-80000
