100kg-500kg Industrial Vacuum Furnace Vacuum Induction Melting Equipment

                                      Vacuum induction melting furnace

100kg-500kg Induction Furnace for Vacuum Induction Melting Advanced Technology

 1,Description and main technical indicators of vacuum induction melting furnace

  AE-ZK-1.0L periodic vacuum induction melting furnace is mainly used for medium-frequency induction heating of various high-temperature alloys, iron-based, nickel-based alloys, cobalt-based alloys and certain non-ferrous metals and their alloys under vacuum or inert gas protection. Melting, smelting, casting and molding are carried out according to the principle.

 ,The furnace has a vertical structure. The smelting chamber and the ingot mold chamber are in the same room. Before smelting, the ingot mold is placed in the furnace chamber. After the smelting is completed, the smelted molten steel is poured into the mold through the observation window. After cooling, , break the vacuum, open the side furnace door and take out the cast ingot mold. Start the next batch of work to achieve cycle production

 2. Main Specifications:

 Smelting furnace technical parameters:

 Rated capacity of electric furnace: 1000kg

 Smelting environment: vacuum or inert atmosphere state.

 Melting working temperature: 1600-1700℃

 High temperature: 1750-2000℃ depending on crucible material

 Ultimate vacuum pressure≤6.67X10-2Pa

 Working vacuum degree ≤6.67X10-1Pa

 Air leakage rate ≤50Pa/S

 Empty time ≤50 minutes

 Maximum loadable power: 600KW

 Melting frequency: 1000Hz

 Average melting speed (power delivery from full material to complete melting): 1000Kg/1-1.5h

 Temperature measurement range: 1000-1800℃

After sales:
1.Installation, Commissioning And Acceptance
We do installation, commissioning and acceptance in buyer's plant.During the installation and commissioning period, the commissioning personnel shall be provided free of charge by the demander according to the staff standard.
The equipment shipped to the buyer, the seller received the buyer's notification, both within a week to carry the equipment out of the box together, then check the equipment and all components according to the packing list . Including equipment accessories, spare parts and special tools, attached manual and technical documents, etc. It can be installed after the acceptance check of equipment.
After installation and debugging, the equipment shall be accepted according to the technical accessories.
2.Training
When taking-over the Furnace to the customer, We will give a staff training to customer. The operating personnel of the customer should join to commission,test the furnace, when installing at customer’s company.
This is practical operation training and practical maintenance training,and our technical personnel will telling the basic principle,equipment maintenance knowledge,And the common fault handling measures.We can training 2 ~ 3 workers. ( Training how to maintenance and operating.)
3. Warranty period
The warranty period of the equipment is 12 months, which starts from the date of installation and debugging of the supplier. Equipment failure happens, after-sales service personnel shall give solutions within 2 hours, after receiving the buyer's notification . If it is need to go to the site for treatment , operators dispatched by seller should arrive at the site within 48 hours after go aboard. In case of emergency,operators should arrive at the site within 48 hours after go aboard, and continue to make repairs until the fault is removed and the equipment returns to normal.
