5 Ton - 150 Ton Capacity Electric Arc Furnace with High Heat Efficiency and Flexible Temperature Control for Steel Smelting

1
MOQ
Negotiation
Price
5 Ton - 150 Ton Capacity Electric Arc Furnace with High Heat Efficiency and Flexible Temperature Control for Steel Smelting
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Arc Furnace
Warranty Of Core Components: 1 Year
Core Components: PLC
Key Selling Points: Competitive Price
Highlight:

Electric Arc Furnace 5 Ton

,

Powerful Electric Arc Furnace

,

Steel Smelting eaf furnace
Basic Infomation
Place of Origin: Shaanxi, China
Brand Name: AE
Certification: CE;ISO9001;ISO14001;OHSAS 18001
Payment & Shipping Terms
Delivery Time: 30-60 work days
Product Description
Powerful Electric Arc Furnace 5 Ton - 150 Ton EAF For Steel Smelting In Manufacturing Plant
The Electric Arc Furnace (EAF) uses electricity as its fuel source, harnessing the high-temperature arc produced between electrodes and furnace charge to melt materials. This industrial-grade equipment is essential for producing various steel grades including normal steel, high-quality carbon steel, alloy steel, stainless steel, and ferroalloys. It serves as a critical component in steel mills, foundries, and ferrous alloy production facilities.
Key Features:
  • Precise temperature control adaptable to different steel grade requirements
  • High thermal efficiency with controllable furnace atmosphere
  • Effective removal of phosphorus, sulfur, oxygen and other impurities to enhance steel quality
  • Precise chemical composition control with stable alloy recovery rates
  • Simplified equipment design with streamlined production process
Advanced Technology Integration:
  • Optimized structural design for maximum efficiency
  • Tubular water-cooled furnace wall and lid system
  • Eccentric Bottom Tapping (EBT) technology
  • Copper-steel composite electrode arms
  • Cluster-type large sectional area water-cooled cables
  • Energy-saving optimized large current system
  • Proportional valve hydraulic system
  • PLC + Industrial computer control system
  • Advanced frequency control and network technology
Complete System Components:
The EAF system includes furnace body, tilting mechanism, furnace cover, support structure, lifting/rotating mechanisms, electrode control system, short net system, cooling system, compressed air system, structural supports, maintenance platforms, hydraulic system, transformer, oxygen lance systems, power distribution systems, and comprehensive computer/PLC control system.
Technical Specifications:
Model Rated Capacity (T) Max Capacity (T) Furnace Shell Inner Diameter (mm) Electrode Diameter (mm) Transformer Capacity (KVA)
EAF-5T 5 10 3200 300 2500-4300
EAF-10T 10 18 3600 350 5500-8000
EAF-15T 15 24 3800 350 8000-12500
EAF-20T 20 30 4000 400 9000-12500
EAF-25T 25 35 4200 400 12500
EAF-30T 30 45 4400 400 12500-25000
EAF-40T 40 55 4600 450 16000-30000
EAF-45T 45 65 4800 450 16000-40000
EAF-60T 60 85 5400 500 25000-60000
EAF-80T 80 100 6100 500 30000-80000
EAF-100T 100 120 6400 550 40000-80000
Tag:

Steel Electric Arc Furnace

Scrap Iron Electric Arc Furnace

100 Tons Electric Arc Furnace
